Awning & Casement Windows
Trango 113 Series Casement & Awning Window
A heavy-duty thermally broken casement window with integrated flyscreen, wide thermal barriers and stainless-steel mesh for demanding, high-performance applications.
Specifications
- Profile wall thickness
- 2.0 mm
- Frame width
- 111.5 mm
- Visible sash dimensions
- flyscreen sash 56 mm, glass sash 72 mm
- Available opening modes
- outward casement, top-hung, outward casement with top-hung
- Opening direction
- flyscreen sash inward opening, glass sash outward opening
- Standard glass
- 5+27A+5 (fluorocarbon-coated aluminium spacer)
- Maximum fixed glass rebate size
- 51 mm
- Thermal barrier width
- outer frame 30 mm, sash 25 mm
- Standard flyscreen mesh
- 0.45 mm diameter, 15-mesh stainless steel mesh
- Glazing
- Double glazed unit: 5 mm glass / 27 mm air / 5 mm glass
- Thermal barrier
- Thermally broken
