Hinged Doors (Outward Opening)
Trango 58 Series Hinged Door (Outward)
A slimline thermally broken aluminium hinged door with narrow 43.5 mm sightlines, maximising glass for light-filled entries and patios.
Specifications
- Profile wall thickness
- 1.4 mm
- Frame width
- 56.9 mm
- Visible sash dimension
- glass sash 43.5 mm
- Available opening modes
- outward opening door, double door, unequal double door
- Opening direction
- glass sash opens outward
- Standard glass
- 5+20A+5 (fluorocarbon insulated aluminium spacer)
- Maximum fixed glass rebate size
- 43.5 mm
- Thermal barrier strip width
- 26 mm
- Glazing
- Double glazed unit: 5 mm / 20 mm air / 5 mm
- Thermal barrier
- Thermally broken
